A dry ice pellet machine is an industrial device that converts liquid carbon dioxide (CO₂) into solid dry ice pellets, blocks, or slices through rapid expansion, cooling, and hydraulic compression. It is widely used in dry ice blasting, cold chain logistics, food preservation, medical transport, stage effects, and industrial cooling. YG Machinery’s dry ice pelletizer is designed with advanced hydraulic compression technology and intelligent control systems. It can produce high-density dry ice pellets with stable output, high efficiency, and low energy consumption. The machine is suitable for customers who need reliable and continuous dry ice production. If you are looking for a high-performance dry ice pellet machine, YG offers a cost-effective and durable solution. Please contact YG now.
YG Dry Ice Pelletizer Parameter
| Equipment Model | YG30 | YG50 | YG100 | YG200 |
| Equipment capacity (kg/hour) | ≤30 | ≤50 | ≤100 | ≤170 |
| Motor power (kilowatts) | 3 | 4 | 5.5 | 7.5 |
| Hydraulic oil tank capacity (liters) | 20 | 50 | 80 | 80 |
| Net weight of equipment (kg) | 108 | 185 | 252 | 320 |
| Weight including wooden crate packaging (kg) | 127 | 218 | 305 | 375 |
| Equipment floor space (square meters) | 0.37m² | 0.51m² | 0.74m² | |
| Equipment dimensions (mm) | 780*480*580/1280 | 880*580*1280 | 1080*680*1320 | |
| Packaging box dimensions (mm) | 950*600*760/1450 | 1030*730*1450 | 1230*830*1480 | |
| Packaged volume (CBM) | 0.4 / 0.74 CBM | 1.1 CBM | 1.52 CBM | |
| Voltage requirements | Two-phase 220V / Three-phase 380V | Three-phase 380V AC power | ||
| System pressure | ≤160 Bar | ≤180 Bar | ||
| Granulation range | Default is 16mm (options: 3, 6, 9, 13, 16, 19mm) | |||
| Granulation density | ≤1550kg/m³ | |||
| Carbon dioxide pressure requirements | 12-22 Bar ≥66ppm | |||
| carbon dioxide consumption | ≥75L /hr | ≥125L / hr | ≥250L / hr | ≥420L / hr |
| Power consumption per hour | ≥4 kWh | ≥5 kWh | ≥7 kWh | ≥9 kWh |
| Operating method | 7-inch color touchscreen & PLC programmable operating system & automated production | |||
| Operating Language | customized | |||
5 Working Process of Dry Ice Pelletizer
- Liquid CO₂ Feeding: Liquid carbon dioxide is first delivered from the storage tank into the system of the dry ice pelletizer.
- Rapid Expansion and Cooling: The liquid CO₂ rapidly expands under pressure reduction and turns into snow-like dry ice particles.
- Hydraulic Compression: The dry ice pellet machine uses a hydraulic system to compress CO₂ snow into high-density dry ice pellets, blocks, or slices.
- Automatic Forming and Cutting: The formed dry ice is automatically shaped and cut into required sizes before being discharged.
- Storage and Application: The final dry ice products can be used in dry ice blasting, cold chain logistics, food preservation, medical transportation, industrial cooling, and so on.
5 Advantages of Dry Ice Pellet Machine
- High Production Efficiency: The dry ice pellet machine adopts a powerful hydraulic compression system, ensuring fast and stable production. It is suitable for continuous industrial operation and large-scale production needs.
- High-Density Dry Ice Production: The dry ice pelletizer produces high-density pellets with slow sublimation, which improves storage time and transportation efficiency, reducing waste and loss.
- Easy Operation with Intelligent Control: The machine is equipped with an intelligent control system that allows automatic adjustment of pressure, temperature, and output. Operators can easily learn and use the equipment with minimal training.
- Stable and Durable Structure: YG dry ice pellet machine is built with high-quality hydraulic components and wear-resistant materials, ensuring long-term stable operation even under heavy workload.
- Low Maintenance Cost: The structure of the dry ice pelletizer is simple and well-designed, making maintenance easy and reducing long-term operating costs for users.
6 Applications of Dry Ice Pelletizer
- Dry Ice Blasting Industry: Automotive engines, mold cleaning, electrical equipment, industrial machinery, and so on. You can use it together with a small dry ice blaster.
- Cold Chain Logistics: Seafood transportation, frozen food delivery, ice cream logistics, fresh food export.
- Medical and Pharmaceutical Industry: The dry ice pelletizer provides stable low-temperature support for vaccine transportation, biological samples, and medicines.
- Aviation and International Shipping: Dry ice is widely used in global cold chain logistics to maintain temperature stability during long-distance transportation.
- Entertainment and Stage Effects: Stage performances, Weddings, Film production, Nightclubs
- Industrial Cooling Applications: Metal shrink fitting, mold cooling, rapid industrial cooling processes.
Why More Companies Choose Dry Ice Pellet Machine
- Reduce Dry Ice Purchase Cost: By producing dry ice in-house, companies can significantly reduce long-term procurement costs.
- Ensure Stable Supply: A dry ice pellet machine allows on-demand production, eliminating supply delays and transportation losses.
- Improve Production Efficiency: Businesses can adjust production volume based on real-time demand, improving flexibility and efficiency.
- Environmentally Friendly Solution: Dry ice is a clean material that does not produce chemical waste or pollution, meeting modern environmental standards.
- Growing Market Demand: Demand for dry ice is rapidly increasing in cleaning, logistics, and medical industries worldwide.
5 Reasons for Choosing the YG Dry Ice Pelletizer
- Stable and Mature Technology: YG has strong experience in manufacturing dry ice pellet machines, ensuring stable performance and reliable production.
- Customizable Design: The dry ice pelletizer can be customized for pellet size, production capacity, voltage standards, and so on.
- Global Export Experience: YG machines are exported worldwide and meet international shipping and usage standards.
- Full After-Sales Support: YG provides installation guidance, video training, technical support, long-term service, and so on.
- High Cost Performance: YG offers competitive pricing while maintaining high quality, making it a cost-effective solution for customers worldwide.
6 FAQs about YG Dry Ice Pellet Machine
A: A dry ice pellet machine can produce different pellet sizes, such as 3mm, 6mm, 9mm, or other customized sizes, depending on customer requirements.
A: Dry ice naturally sublimates over time. However, high-density pellets evaporate more slowly and can be stored for a longer time under proper sealed conditions.
A: Yes. The machine is designed with an industrial-grade hydraulic system and can operate continuously for long production cycles, suitable for factory use.
A: No, maintenance is simple. It mainly involves the hydraulic system, sealing parts, and pressure system. Routine maintenance cost is low.
A: It is widely used in dry ice blasting, the food cold chain, medical transportation, industrial cooling, stage effects, and so on.
A: Yes. It can be customized for pellet size, production capacity, voltage standard, and overall structure according to customer requirements.
