The automatic stretch wrapper, also known as pallet packing machine and wrapping machine for pallets, is intelligent logistics packaging equipment designed for standardized pallet cargo packaging. It replaces traditional manual wrapping to bind stacked goods tightly with stretch film. Equipped with PLC intelligent control system and precision pre-stretch mechanism, these auto stretch wrappers automatically complete full-process wrapping, film cutting, and tail fixing. Suitable for almost all palletized goods in factories, warehouses and logistics parks, it delivers uniform tension, stable packaging quality and high working efficiency. It has become essential standard equipment for modern automated warehousing, with reasonable pallet wrapping machine price and excellent long-term cost performance. If you are interested, please contact Yugong Machinery immediately for more information.
Automatic Stretch Wrapper Parameter
| Model | TP1650SP | TP1650SP-X（including ramp） |
| Turntable Diameter | 1650mm | 1650mm |
| Suitable Pallet Size | （500-1200）*（500-1200）mm | （500-1200）*（500-1200）mm |
| Packaging Height | 500-2000mm | 500-2400mm |
| Turntable Load Capacity | 2000kg | 2000kg |
| Machine Weight | 500kg | 600kg |
| Machine Power | 1.5kw | 1.5kw |
| Power Supply Voltage | 220V/50HZ | 220V |
| Turntable Speed | 0~12rpm | 0~12rpm |
| Applicable Film | 15~35 pre-stretch machine stretch film (25μ recommended) | 15~35 pre-stretch machine stretch film (25μ recommended) |
| Packaging Specifications | 1200*800mm,Height 600mm,Weight under2000kg | 1100*1100mm,Height 2300mm,Weight under 1000kg |
2. Core Product Advantages for Automatic Stretch Wrapper
1. Uniform & Stable Packaging Quality
Manual wrapping often causes uneven tension, loose packaging and cargo collapse. The automatic stretch wrapper maintains consistent film tension and wrapping layers for every pallet. It effectively fixes scattered goods, prevents extrusion, sliding and damage during long-distance transportation and forklift turnover.
2. Intelligent Pre-Stretch Saves Film Cost
Professional pre-stretch structure stretches the original film evenly, improving film utilization by 30%–50%. Compared with manual operation, these auto stretch wrappers greatly reduce daily consumable costs, bringing obvious long-term savings for enterprises with large packaging volume.
3. High Working Efficiency & Labor Saving
One machine can finish dozens of pallets’ packaging per hour. It requires only one worker for simple feeding and collection, greatly reducing labor dependence. It solves the problems of slow manual speed and difficult recruitment of packaging workers.
4. Complete Safety Protection Design
Equipped with photoelectric induction, emergency stop button and anti-collision protection. The sensor automatically detects pallet height to avoid empty wrapping; the machine stops immediately in case of abnormal conditions, ensuring safe workshop operation.
5. Durable Structure & Low Failure Rate
The whole machine adopts thickened steel frame and anti-rust treatment. Core electrical parts use high-quality accessories, supporting long-time continuous operation. Stable performance reduces maintenance frequency and downtime loss.
6. Strong Compatibility & Wide Adaptability
It supports various pallet sizes, cargo heights and load weights. It can wrap cartons, bags, wooden cases and bulk materials, widely adapting to manufacturing, warehousing and freight yard scenarios.
5 Key Benefits for Purchasing Automatic Pallet Machine
1. Reduce Comprehensive Operating Costs
Although there is a one-time equipment investment, the saved labor cost and stretch film consumption can quickly recover the cost. Reasonable pallet wrapping machine price makes the equipment high cost-effective for long-term mass packaging.
2. Improve Enterprise Standardization & Brand Image
Automatically wrapped pallets are neat, uniform and standardized. It avoids messy packaging caused by manual operation, improves overall factory appearance and enhances customer trust in product quality.
3. Lower Cargo Damage & After-Sales Risks
Tight and stable wrapping greatly reduces cargo collapse, collision and moisture damage during transportation. It effectively reduces after-sales compensation and return losses for logistics and manufacturing enterprises.
4. Support 24-Hour Batch Production
These auto stretch wrappers adapt to two-shift and three-shift factory production. Stable continuous working capacity improves warehouse turnover and cargo delivery speed, helping enterprises deliver orders on time.
5. Flexible Upgrade Space
Semi-automatic and fully automatic models are optional. It can be connected with assembly lines, conveyor lines and intelligent warehousing systems later, realizing unmanned integrated packaging and meeting future business expansion demands.
5 Buying Guides for Automatic Stretch Wrapper
1. Confirm Daily Packaging Volume
Small batch and intermittent packaging with a semi-automatic pallet packing machine. For large warehouses and factories with more than 50 pallets per day, fully automatic stretch wrapper is recommended to improve efficiency.
2. Match Pallet Size & Load Weight
Confirm your conventional pallet length, width, height, and single pallet weight. Select the corresponding turntable load and wrapping range to avoid overload operation or insufficient wrapping height.
3. Select Suitable Machine Type
Turntable type is suitable for most conventional cargoes; rotary arm type is better for ultra-light, ultra-heavy, or unstable goods. Online assembly line models are for fully automated production workshops.
4. Compare Configuration & Pallet Wrapping Machine Price
Do not judge only by low price. Focus on pre-stretch ratio, control system brand, safety configuration, and frame thickness. A high-configuration wrapping machine for pallets has a lower failure rate and longer service life.
5. Verify After-Sales Service
Choose manufacturers with complete overseas after-sales support, including English manuals, remote debugging, installation guidance, and long-term spare parts supply, to avoid later maintenance difficulties.
5 FAQs about YG Automatic Stretch Wrapper
A: Yes. It adopts simple PLC touch screen control. Workers can set wrapping layers, speed and tension with one click. New employees can master operation in a short time.
A: Yes. Equipped with photoelectric height detection sensor, it automatically senses the highest point of goods and adjusts the lifting range intelligently.
A: It is suitable for all conventional palletized goods, including carton goods, bagged materials, hardware, electronics, food and chemical products.
A: The professional pre-stretch system improves film utilization greatly, saving 30%–50% stretch film consumption every year compared with manual wrapping.
A: Automation level, load capacity, wrapping speed, pre-stretch function, safety configuration and customized functions are the main factors affecting the final quotation.
Pallet Wrapping Machine Price-Choose YG Machinery
Stop wasting labor costs and stretch film on inefficient manual packaging! If you are looking for stable automatic stretch wrapper and cost-effective wrapping machine for pallets, our high-quality auto stretch wrappers with competitive pallet wrapping machine price are your best choice. Upgrade your packaging process now, reduce operating costs, stabilize cargo quality and improve your overall market competitiveness! If you are interested, please contact YG for a discount.
