YG EV charging stations are designed for both residential and commercial applications, offering stable performance and flexible configurations. Whether you need a home solution or a rapid electric car charger for public use, our systems provide efficient and reliable charging. With competitive car charging station prices and optimized electric charger costs, YG helps users balance investment and performance while supporting the growing EV market.
Commercial EV Charging Stations Parameter
| Product number | YG-60KW | YG-80KW | YG-120KW | |
| Detailed specification | rated power | 60KW | 80KW | 120KW |
| Charging equipment | User Interface | 7-inch LCD color display touchscreen | ||
| installation | Floor-standing/Down in down out | |||
| Routing mode device size | 635*423*1600(mm) | |||
| Input voltage | AC380V±20% | |||
| Input frequency | 45~65Hz | |||
| The output voltage | 200-750VDC | |||
| Single gun output current range | 200V-500V | 200V-500V | 200V-500V | |
| The output voltage | 0-90A | 0-120A | 0-160A | |
| Single gun output current range | 200V-750V | 200V-750V | 200V-750V | |
| The output voltage | 0-60A | 0-80A | 0-107A | |
| Charging equipment | Single gun output current range | 0-112A | 0-150A | / |
| Cable length | 5m | |||
| Electrical index | Measurement accuracy | Level 0.5 | ||
| Current limit protection value | ≥110% | |||
| Voltage regulation accuracy | ≤±0.5% | |||
| Steady flow accuracy | ≤±1% | |||
| Ripple coefficient | ≤±0.5% | |||
| effectiveness | ≥94.5% | |||
| Power factor | ≥0.99 (50% load or more) | |||
| Harmonic content THD | ≤5% (50% load or more) | |||
| Feature design | HMI | 7-inch LCD color display touch screen, LED indicator | ||
| Charging mode | Auto full / fixed power / fixed amount / fixed time | |||
| payment method | Credit card payment / APP payment /Scan code payment | |||
| Communication Interface | Ethernet 2/3/4G (optional) | |||
| Safety design | Executive standard | GB\T 20234, GB/T 18487, GB/T 27930, NB\T 33008 | ||
| security function | Charge gun temperature detection, overvoltage protection, undervoltage protection, overload protection, short circuit protection, grounding protection, over-temperature protection, low-temperature protection, insulation monitoring protection, polarity reverse connection protection, lightning protection, emergency stop protection, leakage protection | |||
| Environmental indicators | Operating temperature | -25°C~+50°C | ||
| Working humidity | 5%~95% non-condensing cream | |||
| Working elevation | <3000m | |||
| Protection level | IP54 | |||
| cooling method | Forced air cooling | |||
| Noise control | ≤60dB | |||
| MTBF | 100,000 hours | |||
Case Study 1: Home EV Charging Solution in Italy
Client Background
The client is a private EV owner in Italy who recently purchased an electric vehicle and wanted a convenient home charging solution for daily use.
Challenges Encountered
- Limited Public Charging Access: Nearby charging stations were sometimes occupied, especially during peak hours.
- Daily Charging Convenience: The client needed a simple and reliable solution for home charging.
- Cost Consideration: The client was concerned about the overall electric charger cost and long-term usage.
Solution
We recommended a home charging unit that works as a fast charger for an EV car, featuring:
- Compact wall-mounted design
- Stable and safe charging performance
- Easy installation with the existing home power system
- Cost-effective solution with a reasonable car charging station price
The unit was installed in the garage, providing a dedicated charging point.
Results
- Convenient Charging: The client can charge the vehicle anytime at home.
- Stable Performance: The charger operates reliably for daily use.
- Cost Control: Balanced upfront electric charger cost with long-term convenience.
- Easy Installation: Quick setup without complex modifications.
Client Feedback
“This fast charger for EV cars is very convenient. I can charge overnight at home without worrying about availability or high costs.”
Case Study 2: Commercial Charging Project in Russia
Client Background
The client is a commercial operator in Russia, planning to install charging stations in a public parking area to attract EV users and create additional revenue.
Challenges
- Growing EV Demand: More EV users require accessible charging solutions.
- Efficiency Requirements: The system needed to support frequent use with stable output.
- Investment Planning: The client wanted a solution with a reasonable car charging station price and a controllable electric charger cost.
Solution
We supplied a rapid electric car charger system, configured as follows:
- Designed for commercial use with stable output
- Supports continuous operation in public areas
- Compatible with different EV models
- Optimized the balance between performance and electric charger cost
These units function as an efficient fast charger for EV car solutions in high-traffic areas.
Results
- Increased Traffic: Charging services attracted more EV users to the location.
- Reliable Operation: The system maintained stable performance under regular usage.
- Revenue Growth: Provided an additional income stream for the client.
- Balanced Investment: Achieved a practical balance between the car charging station price and long-term return.
Client Feedback
“The rapid electric car charger works well for our business. It’s reliable, easy to manage, and helps attract more customers.”
Summary
YG EV charging stations provide flexible and practical solutions for both home and commercial use:
- Suitable for residential and public scenarios
- Options from home units to rapid electric car charger systems
- Competitive car charging station price and optimized electric charger cost
- Reliable performance for daily and high-frequency use
Our fast charger for EV car solutions has been successfully used in Italy, Russia, and other markets, supporting the expansion of EV infrastructure worldwide.
