Skid steer electrics are widely used in construction, mining, road building, port logistics, and agricultural operations. They mainly perform tasks such as loading, carrying, pushing, leveling, and short-distance transportation through the front bucket. With growing attention to green energy and low carbon emissions worldwide, electric construction machinery is becoming a new trend. YG Machinery from Henan has developed an electric skid steer, featuring an advanced electric drive system, intelligent control technology, and excellent performance, making it ideal for mining, construction, and logistics applications. If you want to learn more, please contact YG now.
Skid Steer Electric Technical Parameter
| Performance | Rated Load（t) | 1.0 | |
| Bucket rated capacity（m)³ | 0.4 | ||
| Dumping height（mm) （at 45°） | 2260 | ||
| Dumping Reach（mm) | 520 | ||
| Max. Lifting weight（kg） | 1000 | ||
| Max. Excavation Force（kn) | 1800 | ||
| Max. Grade ability | 30° | ||
| Max. Turning Angel | 38°±1 | ||
| Dimensions. &.Weight | Overall length（Bucket on Ground position）mm | 4480 | |
| Bucket width（overall width） | 1600 | ||
| Overall Height(mm) | 2460 | ||
| Min Ground Clearance(mm) | 240 | ||
| Net Weight（kg) | 2800kg | ||
| Turning Radius | 3800mm | ||
| Tyres | Type | 31*15.5-15 | |
| pressure（mpa) | 0.3 | ||
| Qty | 4 | ||
| Engine | Model | 云内DEF20NJF4 | |
| Power | 18.8kw | ||
| Speed | 2400r/min | ||
| Steering System | Type of Steering Hydraulic System | Full Hydraulic Steering System | |
| System Pressure（mpa) | 16 | ||
| Type of Steering Pump | External Gear Pump | ||
| Steering Cylinder Bore（mm) | 63 | ||
| Qty（pc） | 2 | ||
| Distribution Valve | Model | DL10 | |
5 Features of Skid Steer Electric
- Zero Emissions and Energy Saving: Compared with traditional diesel skid steers, YG electric skid steers are fully powered by electricity, producing zero tailpipe emissions. They meet strict environmental standards and are especially suitable for urban construction, indoor warehouses, and tunnel projects. The electric system is highly efficient, saving energy and reducing operating costs over time.
- Low Noise and Comfortable Operation: The electric drive system runs smoothly, with noise reduced by over 50% compared to diesel engines. Perfect for indoor work or residential areas, it minimizes disturbance to people and the environment. The cabin is designed for comfort, with sound insulation and intelligent air conditioning, providing a pleasant working experience.
- Powerful Performance and Stability: Despite being electric, YG skid steers deliver performance comparable to diesel models. With a high-efficiency motor and advanced hydraulic system, the bucket responds quickly with high torque, ensuring stable operation under heavy loads.
- Intelligent Management System: The skid steer is equipped with a smart control module to monitor battery status, working hours, load conditions, and maintenance alerts. The remote management system allows users to optimize schedules and maintenance, improving operational efficiency.
- Simple Maintenance and Long Lifespan: The electric skid steer has a simpler structure, reducing the need for complex engine, exhaust, or fuel system maintenance. Modular battery and motor designs make replacement and upkeep easy, lowering long-term maintenance costs.
4 Applications of YG Electric Mini Skid Steer
- Urban Construction and Municipal Projects: Electric skid steers are ideal for city roads, landscaping, and underground pipeline work. Their zero emissions and low noise allow safe operation near residents or at night.
- Mining Operations: With high torque and continuous working ability, electric skid steers are perfect for loading, stacking, and transporting minerals. Zero emissions in tunnels and enclosed areas protect workers’ health.
- Warehouse and Port Logistics: Electric skid steers handle materials efficiently in warehouses and ports, reducing fuel costs and noise, and can operate easily indoors.
- Renewable Energy Projects and Industrial Parks: They are suitable for renewable energy sites and industrial parks, helping companies maintain a green image and comply with government energy-saving policies.
5 Skid Steer Electric Advantages for Personal Buyers
- Suitable for Small Jobs: YG electric skid steers come in various sizes and configurations. They are ideal for personal warehouses, yard work, or small farms, without the space and complexity required by large diesel machines.
- Low Operating Costs: Electric drive reduces fuel and maintenance expenses. For personal users, long-term savings make the investment economical.
- Eco-Friendly and Quiet: Zero emissions and low noise make the skid steer suitable for residential areas, farms, or private projects, without disturbing neighbors.
- Easy to Operate: With an intelligent control system, the skid steer is intuitive to start, drive, and operate. Even users without professional experience can quickly use it.
- Multi-Purpose and High Value: Personal buyers can use it for moving, stacking, and yard work, or even rent it out for extra income, maximizing value.
6 Reasons Why Skid Steer Electric Are Popular
- Significant Cost Savings: Electric skid steers use electricity instead of diesel and have lower maintenance requirements. The total cost of ownership is lower, benefiting both companies and individuals.
- Improved Green Image and Compliance: Using electric skid steers in urban or industrial projects reduces emissions and noise, meeting government environmental regulations. Personal users also avoid neighbor complaints.
- High Efficiency and Quick Response: Electric drive provides stable torque and fast bucket response, saving time in mining, construction, or warehouse operations.
- Smart Management Reduces Risks: Battery monitoring, fault alerts, and remote scheduling reduce downtime and accidents. Companies can optimize project planning, while personal users can easily monitor equipment.
- Flexible Application and Quick ROI: From private yards to mining sites, there are models to fit all needs. Companies can deploy across projects, and personal users can use smaller models for multiple tasks, improving ROI.
- Comfortable and Safe Operation: Low noise, zero emissions, and smooth driving reduce operator fatigue and improve safety for both company employees and individual users.
5 Reasons to Choose YG Electric Skid Steer
- Long-Term Cost Savings: Advanced battery management and operational optimization lower long-term costs, providing better ROI than competitors.
- Comprehensive After-Sales Service: YG provides nationwide and international support, from installation to maintenance and emergency repair, ensuring stable operation.
- Trusted Brand with Industry Experience: With over 20 years in machinery manufacturing and service to 100+ countries, YG is a reliable and proven brand.
- Customizable for Diverse Needs: Models can be customized for bucket capacity, battery range, and control system, offering solutions tailored to the project.
- Supports Green Development Goals: Choosing YG electric skid steers helps companies implement low-carbon strategies and improve corporate social responsibility.
3 FAQs about YG Skid Steer Electric
Q: What work environments suit electric skid steers?
A: They are suitable for urban construction, mining, warehouse and port logistics, industrial parks, and personal farms. Perfect for noise- or emission-sensitive environments.
Q: How does it compare to diesel skid steers?
A: YG electric skid steers are zero-emission, low-noise, energy-efficient, and cost-effective, with intelligent control and reliable performance.
Q: Is maintenance difficult?
A: No. Electric skid steers have a simple structure, mainly maintaining the battery, motor, and hydraulic system. Modular design makes it easy and affordable.
