The solar pile driver machine uses a high-performance hydraulic system and stable power structure, providing strong piling capability and excellent construction stability. The equipment can adapt to various soil conditions and supports different specifications of photovoltaic piles. It features high working efficiency, precise positioning, low labor cost, and strong adaptability to complex terrains. It is widely used in large-scale ground solar power plants, mountain photovoltaic projects, agricultural-solar hybrid projects, and distributed photovoltaic systems. For more details, please contact YG.
YG Solar Pile Driver Technical Parameter
| Hydraulic photovoltaic pile driver | |||
| Overall dimensions | 4700*2100*2800mm | Drill pipe rotational speed | 180r/min |
| Track shoe width | 400mm | gradability | 30° |
| motor | 4108 | rock hardness | 6-20F |
| Drilling diameter | 80-500mm | Slide tilt angle | 120° |
| Drilling depth | 0-6m | Drill arm swing angle | left and right150° |
| Reducer torque | 13000n.m | Slide swing angle | left and right40° |
| Mainstream pump | triple pump | Driving speed | 0-3km/h |
| oil pump | 40/40/32 | ||
| Crawler photovoltaic pile driver | |||
| Overall dimensions | 4700*2200*2800mm | Hydraulic hammer flow | 50-110L/min |
| Track shoe width | 400mm | Impact frequency | 350-800BMP |
| motor | 4108 | Hydraulic system pressure | 25mpa |
| Generator power | 88kw Motor | Strong wind for heat dissipation | yes |
| Drilling depth | 0-6m | oil pump | 40/40/32 |
| Drilling diameter | 80-600mm | Driving speed | 3km/h |
6 Working Principle of Solar Pile Driver Machine
- Equipment Positioning: The machine first moves to the construction area and determines pile positions according to drawings. A solar pile driver machine ensures an accurate layout for large-scale projects.
- Pile Placement: The photovoltaic pile is placed in the correct position and fixed using a clamping system.
- Vertical Adjustment: Operators adjust the pile verticality using the hydraulic control system to ensure precision.
- Hydraulic Power Activation: The system starts the hydraulic impact or vibration system to provide a strong driving force. This is a key feature of a photovoltaic pile driver.
- Pile Driving Process: Under vibration or impact force, the pile is driven into the ground until it reaches the required depth. A solar pile driver machine ensures consistent performance.
- Continuous Operation: After finishing one pile, the machine moves quickly to the next position for continuous work.
5 Core Advantages of Solar Pile Driver Machine
- High Piling Efficiency: The YG system uses a powerful hydraulic drive, enabling fast pile installation. A photovoltaic pile driver significantly improves construction speed for large solar farms.
- High Construction Precision: The hydraulic control system ensures accurate vertical alignment and depth control, improving overall structural stability.
- Strong Adaptability to Complex Terrain: The solar pile driver machine can operate in
- mountains
- deserts
- mud fields
- gravel land
- farmland
- Reduced Labor Cost: Compared with manual construction, the photovoltaic pile driver greatly reduces labor requirements and construction time.
- Durable and Stable Structure: High-strength steel structure ensures long-term stable operation even under harsh environments such as heat, wind, and sand.
8 Applications of the photovoltaic pile driver
- Large-Scale Solar Power Plants: A solar pile driver machine is widely used in large photovoltaic farms to install massive pile foundations efficiently.
- Mountain Photovoltaic Projects: The equipment can adapt to slopes and uneven terrain, making it ideal for mountain solar installations.
- Desert Solar Projects: In desert environments, the photovoltaic pile driver performs well under high temperatures and sandy soil conditions.
- Agricultural-Solar Hybrid Projects: Used for installing solar structures in farmland, improving land utilization efficiency.
- Fishery-Solar Hybrid Projects: Suitable for pile installation in fish ponds and aquaculture areas.
- Distributed Solar Projects: Used in factories, industrial parks, and warehouse rooftop support systems.
- Highway Slope Solar Projects: A solar pile driver machine can work in narrow roadside and slope environments.
- Renewable Energy Infrastructure Projects: Besides solar, the equipment can also be used for wind power foundations and guardrail installation.
Why More Customers Choose Solar Pile Driver Machine
- Rapid Growth of Solar Industry: Global demand for solar energy continues to increase, driving higher demand for foundation construction equipment.
- Faster Construction Speed: Mechanized piling greatly shortens project timelines and increases overall profitability.
- Lower Construction Cost: The photovoltaic pile driver reduces labor input and operational expenses.
- Strong Adaptability: Suitable for complex terrains such as mountains, deserts, and farmland.
- Higher Construction Quality: Accurate piling improves structural stability and reduces maintenance issues.
5 Reasons for the YG Solar Pile Driver Machine
- Stable Hydraulic System: YG provides a reliable hydraulic system, ensuring consistent power output for the solar pile driver machine.
- Strong and Durable Structure: High-strength steel materials ensure long service life under heavy-duty conditions.
- Multiple Pile Compatibility: The photovoltaic pile driver supports various pile types and project requirements.
- Strong Customization Ability: YG can customize
- pile depth
- hydraulic system
- crawler structure
- power configuration
- Full After-Sales Support: YG provides installation guidance, video training, technical support, and long-term service.
8 FAQs of YG Solar Pile Driver Machine
A: The solar pile driver machine can handle photovoltaic screw piles, C-type steel piles, and H-type steel piles.
A: Yes, the photovoltaic pile driver is suitable for mountains, deserts, gravel land, and muddy areas.
A: Yes, compared with manual construction, the hydraulic system greatly improves efficiency.
A: Yes, YG equipment is compact and easy to relocate between project sites.
A: No, a portable helical pile driver style control system makes operation simple after basic training.
A: Yes, YG provides full customization according to project requirements.
A: No, the system applies even force and ensures stable installation quality.
A: Yes, YG offers installation guidance, training videos, spare parts, and long-term service support.
