This fast wood splitter machine is a fully automatic, gasoline-powered firewood processing equipment. Featuring a fast 7–8 seconds cycle time and high working efficiency of 4–5m³/h, this fast wood splitter easily handles logs with a maximum diameter of 380–400 mm. Compared with a traditional mechanical wood splitter, it saves massive labor and greatly improves output. With flexible mobility, durable structure, and competitive wood splitter price, it is ideal for farm maintenance, landscaping waste recycling, and commercial firewood production. If you are interested, please contact YG for a discount.
Automatic Firewood Splitter Parameter
| Max Splitting Force | 15T | 20T |
| Cycle Time | 7seconds | 8seconds |
| Max Splitting Length | 610mm | 610mm |
| Max Splitting Diameter | 380mm | 400mm |
| Work Efficiency | 4m3/h | 5m3/h |
| Power | 15HP gasoline engine | 15HP gasoline engine |
| Engine Displacement | 420cc | 420cc |
| Fuel Tank Capacity | 6.5L | 6.5L |
| Engine Oil Capacity | 1.1L | 1.1L |
| Gross Torque | 25N.m/2500rpm | 25N.m/2500rpm |
| Firewood Conveyor | Length:3.2m | Length:3.2m |
| Width of belt:250mm | Width of belt:250mm | |
| Width of chute:400mm | Width of chute:400mm | |
| Hydraulic rotator:1set | Hydraulic rotator:1set | |
| Chain Saw length | 1.2m | 1.2m |
| Chain Saw Rotate Speed | 5600rpm | 5600rpm |
| Sawing Speed | Adjustable | Adjustable |
| Oil Pump | 22GMP, 2-stage | 22GMP, 2-stage |
| Oil Tank Capacity | 50L | 50L |
| Control Valve | ONE-handle | ONE-handle |
| 4-Directional control valve | 4-Directional control valve | |
| Tyre | 12″ | 12″ |
| Knife | 4 ways (6 ways option) | 4 ways (6 ways option) |
| Weight | 480kg | 510kg |
| The Main Machine Package size | 2200*900*1100mm | 2200*900*1100mm |
| Conveyor Package Size | 2260*960*1170mm | 2260*960*1170mm |
The wood chipper has a 5-step workflow and 5 main components. For more information, please click to learn more about the fast wood splitter.
Case Study 1: USA – Commercial Firewood Processing Factory
Customer Background
The customer is a large local firewood supplier in the United States, focusing on commercial firewood production, packaging, and wholesale. They supply bulk firewood for residential heating, camping parks, and outdoor resorts all year round, with large daily wood splitting demand.
Customer Difficulties
The customer previously used an ordinary mechanical wood splitter with a slow cycle speed and low work efficiency. Old equipment cannot process large-diameter logs, resulting in lots of leftover waste wood. Manual auxiliary feeding and sorting wasted massive labor costs. Their old machines only reach 2–3m³/h output, which cannot support growing order volume, and the overall comprehensive cost is high.
Solution
After comparing multiple suppliers and checking the wood splitter price, the customer placed a repeat order for our 20T hydraulic wood splitter machine. Equipped with an 8s ultra-fast cycle time, 400mm max splitting diameter, and 5m³/h high working efficiency, the machine matches large-batch commercial production perfectly. The 15HP gasoline engine, 3.2m automatic conveyor, and adjustable sawing speed fully meet long-time continuous working needs.
Application Effect
The 20T fast wood splitter supports 4-way or optional 6-way splitting knives, realizing uniform firewood molding. The 5600rpm high-speed chainsaw improves cutting flatness, while the 22GMP two-stage oil pump ensures stable hydraulic output. The hourly output reaches 5m³, greatly improving production capacity. The 12-inch mobile tire design allows flexible site transition, and the 50L large oil tank supports all-day non-stop operation, completely solving the production bottleneck.
Customer Feedback
“This 20T hydraulic wood splitter machine is our best production upgrade. Fast cycle time, large splitting diameter, and stable power output. The wood splitter price is very competitive, and it replaces multiple old mechanical wood splitter units. Our firewood output increased significantly.”
Wood chippers have 8 classic application scenarios. To learn more, please click on the 8 application scenarios of wood chippers.
Case Study 2: Saudi Arabia – Landscape & Farm Maintenance Contractor
Customer Background
A comprehensive engineering contractor based in Saudi Arabia, mainly undertaking urban greening pruning, orchard maintenance, and rural farm wood waste recycling projects. They need mobile, high-efficiency wood processing equipment for field operation.
Difficulties
Local desert climate leads to hard and dry tree trunks and branches. Ordinary splitters are weak in splitting force and prone to jamming. Most equipment on the market is bulky and inconvenient to move in scattered outdoor working sites. The customer needed a portable, high-torque, fast wood splitter that adapts to harsh, high-temperature working conditions.
Solution
We recommended our hot-selling 15T hydraulic wood splitter machine for the customer’s field operation scenarios. With 7s super-fast cycle time, 380mm maximum splitting diameter, 4m³/h efficiency, and 25N · m high torque gasoline engine, it easily splits local hard dry wood. The integrated mobile tire design and one-handle 4-directional control greatly improve field operation convenience.
Effect
The 420cc high-displacement gasoline engine provides stable power under high-temperature environments. The matched hydraulic rotator and 3.2m long conveyor realize automatic feeding and discharging, reducing manual work. The 480kg compact body and integrated package size are convenient for field transportation and deployment. It perfectly handles garden pruning wood, orchard waste logs, and landscape residual materials, achieving 100% wood resource recycling.
Customer Feedback
“We are very satisfied with this fast wood splitter. It runs stably in high temperature splits hard, dry wood effortlessly. Simple one-hand control saves lots of time and labor. Worth every penny of the wood splitter price.”
4 FAQs about YG
15T model has 7s cycle time, 380mm max diameter and 4m³/h efficiency; 20T model has 8s cycle time, 400mm diameter and 5m³/h higher output. The 20T model (510kg) is more suitable for commercial mass production, while 15T (480kg) fits mobile field work.
Yes. Equipped with 15HP professional gasoline engine, independent 50L hydraulic oil tank and heat-resistant hydraulic system, it adapts to long-time high-load operation.
Absolutely. It adopts 4-way standard splitting knives with optional 6-way knives, and the sawing speed is adjustable, allowing users to customize firewood size according to market demands.
Yes. Compared with traditional mechanical wood splitter, it greatly cuts labor cost, improves output, and has low failure rate. The complete machine has few vulnerable parts, bringing ultra-high long-term return on investment.
