Moving heavy machinery should not become the slowest part of your warehouse operation.
If your workers spend too much time repositioning equipment, need several people to move one machine, or your existing handling method can no longer cope with heavier loads, it may be time to consider an electric machinery skate.
YG’s heavy duty moving skates are designed for different towing requirements, with models from 10 tons to 60 tons. Whether you need a 30 ton electric machinery skate for medium-heavy machinery or a higher-capacity 60 ton electric transfer solution, choosing the right model starts with understanding your actual load and working conditions.
But buying a heavy-duty moving solution is not simply about choosing the biggest model.
You need to consider the maximum towing weight, motor power, battery, drive wheels, machine dimensions, controller, and available working space. The right choice can help you build a more suitable system for moving heavy equipment around your warehouse or factory. Want to learn more details? Please contact YG at +86 139 3718 3205.
Get 12-Month Warranty & 24/7 Technical Support – Learn More
1. Your Workers Spend Too Much Time Moving Heavy Equipment
The first sign is simple: moving equipment takes too much time.
In many warehouses and factories, workers may spend valuable time positioning large machinery. A machine may need to be moved between production areas, repositioned for maintenance, or transferred within the workshop.
As equipment becomes heavier, manual movement becomes increasingly difficult to organize.
This is where heavy duty moving skates can provide a powered alternative. Instead of relying mainly on manual force, an electric drive system provides the movement power.
YG Heavy Duty Moving Skate Models
| Model | Motor | Maximum Towing Weight | Drive Wheels |
|---|---|---|---|
| YG-10 | 500W | 10 tons | 4 |
| YG-20 | 750W | 20 tons | 4 |
| YG-30 | 1000W | 30 tons | 4 |
| YG-40 | 1500W | 40 tons | 4 |
| YG-50 | 2000W | 50 tons | 4 |
| YG-60 | 3000W | 60 tons | 8 |
If your warehouse regularly needs to move equipment around the 30-ton range, a 30-ton electric machinery skate can be a suitable model to investigate.
2. Your Equipment Is Getting Heavier Every Year
A warehouse may start with relatively small machines, making manual transportation seem perfectly reasonable.
Then the business grows.
New production equipment arrives. Larger machinery is installed. Heavy components need to be repositioned. Maintenance work requires equipment to be moved more frequently.
Eventually, the handling method that worked before may no longer match the actual weight of the equipment.
Choose the Towing Capacity According to Your Load
| Model | Maximum Towing Weight | Suitable Capacity Level |
|---|---|---|
| YG-10 | 10 tons | Up to 10 tons |
| YG-20 | 20 tons | Up to 20 tons |
| YG-30 | 30 tons | Up to 30 tons |
| YG-40 | 40 tons | Up to 40 tons |
| YG-50 | 50 tons | Up to 50 tons |
| YG-60 | 60 tons | Up to 60 tons |
The YG-60 is the highest-capacity model in the listed range. It uses two 3000W motors, a 48V 100AH ternary lithium battery, and eight drive wheels, with a maximum towing weight of 60 tons.
For warehouses handling very heavy machinery, a 60 ton electric transfer solution may be worth considering.
The key rule: Choose the machine according to the actual towing requirement, not simply the size of the equipment.
Get 12-Month Warranty & 24/7 Technical Support – Learn More
3. Moving Machinery Requires Too Many People
Another warning sign is the number of people needed to move one piece of machinery.
Imagine a large machine that needs to be repositioned inside a workshop. If several workers need to coordinate when to push, stop, turn, or reposition the equipment, the process becomes more complicated as the load gets heavier.
An electric machinery skate changes the basic approach by using an electric drive system to provide the movement power.
YG models use two motors with brakes, with motor power ranging from 500W to 3000W.
Motor and Battery Comparison
| Model | Motor Configuration | Battery | Drive Wheels |
|---|---|---|---|
| YG-10 | 2 × 500W | 48V 30AH ternary lithium | 4 |
| YG-20 | 2 × 750W | 48V 60AH ternary lithium/lithium iron phosphate | 4 |
| YG-30 | 2 × 1000W | 48V 60AH ternary lithium/lithium iron phosphate | 4 |
| YG-40 | 2 × 1500W | 48V 120AH ternary lithium/lithium iron phosphate | 4 |
| YG-50 | 2 × 2000W | 48V 120AH ternary lithium/lithium iron phosphate | 4 |
| YG-60 | 2 × 3000W | 48V 100AH ternary lithium | 8 |
This range gives warehouses different options instead of requiring every customer to use the same machine.
4. Your Warehouse Needs More Flexible Equipment Movement
A warehouse is rarely static.
Production layouts change. Equipment may need maintenance. New machinery may arrive. Existing machinery may need to be moved to another position.
If your material handling system only works well for one fixed route, it may become difficult to adapt to these changes.
This is another situation where heavy-duty moving skates may be worth considering.
However, capacity is not the only factor. The physical size of the machine also needs to match the available working space.
YG Model Dimensions
| Model | Approximate Dimensions |
|---|---|
| YG-10 | 500 × 550 × 145 mm |
| YG-20 | 670 × 620 × 165 mm |
| YG-30 | 740 × 640 × 185 mm |
| YG-40 | 810 × 800 × 182 mm |
| YG-50 | 810 × 800 × 182 mm |
| YG-60 | 1110 × 880 × 185 mm |
A smaller warehouse moving lighter equipment may not need the largest model.
A heavy industrial facility moving equipment up to 60 tons may require a higher-capacity solution.
The right model should match the:
- Equipment weight
- Required towing capacity
- Available working space
- Machine dimensions
- Movement requirements
5. You Need a More Controlled Way to Move Heavy Loads
The fifth sign is that your warehouse needs a more controlled way to move heavy equipment.
As loads become heavier, simply getting the equipment moving is not the only consideration. Operators also need a practical way to control the movement process.
For applications where remote operation is part of the selected configuration, a remote-controlled load-moving dolly can be an attractive option.
The exact operating arrangement depends on the machine configuration and application, so buyers should confirm the control system and operating method with the supplier before ordering.
Controller Comparison
| Model | Controller |
|---|---|
| YG-10 | D2T80A |
| YG-20 | D2T80A |
| YG-30 | D2T100A |
| YG-40 | D2T200A |
| YG-50 | D2T200A |
| YG-60 | D2T200A |
The controller specification varies across the range according to the different electrical requirements of each model.
Get 12-Month Warranty & 24/7 Technical Support – Learn More
How to Match the Model to Your Application
Choosing an electric machinery skate should start with one simple question:
How heavy is the equipment you need to move?
However, towing capacity is not the only factor. The size of your machinery, available working space, movement frequency, and operating requirements should also be considered.
The table below gives you a quick way to compare each YG model and understand which type of application it may be suitable for.
YG Electric Machinery Skate Model Selection Guide
| Model | Max. Towing Weight | Motor | Drive Wheels | Approx. Dimensions | Suitable Applications | Recommended For |
|---|---|---|---|---|---|---|
| YG-10 | 10 tons | 500W | 4 | 500 × 550 × 145 mm | Moving small and medium machinery, workshop equipment, machine parts, and lighter industrial loads | Small workshops, equipment maintenance areas, factories with loads up to 10 tons |
| YG-20 | 20 tons | 750W | 4 | 670 × 620 × 165 mm | Moving medium-heavy machinery, production equipment, molds, and industrial components | General manufacturing plants and workshops handling loads up to 20 tons |
| YG-30 | 30 tons | 1000W | 4 | 740 × 640 × 185 mm | Moving heavy machinery, large equipment, industrial machines, and equipment for maintenance or repositioning | Heavy machinery workshops and factories with loads around 30 tons |
| YG-40 | 40 tons | 1500W | 4 | 810 × 800 × 182 mm | Moving larger production machines, heavy industrial equipment, and machinery between working areas | Heavy manufacturing facilities handling loads up to 40 tons |
| YG-50 | 50 tons | 2000W | 4 | 810 × 800 × 182 mm | Moving very heavy machinery, large industrial equipment, and heavy components | Large factories and industrial facilities with loads up to 50 tons |
| YG-60 | 60 tons | 2 × 3000W | 8 | 1110 × 880 × 185 mm | Moving extremely heavy machinery and large industrial equipment where higher towing capacity is required | Heavy industrial plants and facilities handling loads up to 60 tons |
Quick Selection by Load Weight
| Your Equipment Weight | Model to Consider | Typical Application |
|---|---|---|
| Up to 10 tons | YG-10 | Workshop equipment, machine parts, small industrial machinery |
| 10–20 tons | YG-20 | Production equipment, molds, medium-heavy machinery |
| 20–30 tons | YG-30 | Heavy machinery, large industrial equipment |
| 30–40 tons | YG-40 | Heavy production machinery and industrial equipment |
| 40–50 tons | YG-50 | Large machinery and heavy industrial components |
| 50–60 tons | YG-60 | Very heavy machinery and large industrial equipment |
Which YG Model Is Right for Your Warehouse?
If you are not sure which model to choose, use these practical questions:
| Question | What to Consider |
|---|---|
| How heavy is your equipment? | Start with the maximum towing weight you need |
| How often do you move it? | Frequent movement may require a more suitable powered solution |
| How much working space do you have? | Compare the dimensions of the skate with your warehouse layout |
| What type of machinery are you moving? | Consider the size and shape of the equipment |
| How many people are currently needed? | If several workers are required, powered movement may be worth considering |
| Do you need higher towing capacity? | Compare the 10–60 ton YG range |
| Do you need a specific control arrangement? | Confirm the controller and operating configuration with YG |
A simple rule: Choose the model based on your actual towing requirement first, then check the dimensions, motor, battery, drive wheels, and working environment.
If your equipment is around 30 tons, the YG-30 is a natural model to investigate. If your application involves loads approaching 60 tons, the YG-60 provides the highest towing capacity in this range.
Get 12-Month Warranty & 24/7 Technical Support – Learn More
Why Choose YG Heavy Duty Moving Skates?
YG provides six models covering maximum towing capacities from 10 tons to 60 tons.
The range includes compact models for smaller heavy-duty movement and higher-capacity models for heavier industrial applications.
Whether you need a 30 ton electric machinery skate, a higher-capacity 60 ton electric transfer, or a remote-controlled load-moving dolly for a specific application, the most important step is to match the machine to the actual load and working environment.
Choose Your Moving Solution Step by Step
Load Weight
↓
Required Towing Capacity
↓
Machine Dimensions
↓
Battery & Motor Configuration
↓
Drive Wheels & Controller
↓
Available Working Space
↓
Final Model Selection
This approach is more practical than simply choosing the largest model.
Don’t Let Momentary Hesitation Hinder Your Business Development – Contact YG Now!
Manual material handling may be suitable when equipment is relatively light and movement distances are short.
But when machinery becomes heavier, movement becomes more frequent, and workers spend too much time repositioning equipment, your existing system may become a bottleneck.
Electric moving equipment provides another option for heavy machinery transportation.
From the compact YG-10 to the high-capacity YG-60, YG offers different models for different towing requirements.
The right choice depends on your actual load, working space, movement requirements, and equipment configuration.
Need a heavy duty moving skate for your warehouse or factory? Contact YG and tell us what you need to move, how heavy it is, and where it needs to go.
